3-gang with (1) blank (1) duplex (1) blank, standard size, painted metal wallplate

Construction: Painted metal; cold-rolled steel, 0.030 inches thick
Gang: 3
Size: Standard (4.5 in. high x 6.375 in. wide)
Opening: (1) blank (1) duplex (1) blank
Mounting: (Blank) box mounting (3.281 in. between mounting holes) / (Duplex) device mounting / (Blank) box mounting (3.281 in. between mounting holes)


Additional Information

Product Type: Wallplates

FINISH CAT. NO. / UPC
White Semi-Gloss
86193
95327861939.0
White Wrinkle
85193
95327851930.0
Ivory Semi-Gloss
84193
95327841931.0
Ivory Wrinkle
99193
95327991933.0
Brown Semi-Gloss
82193
95327821933.0
Brown Wrinkle
98193
95327981934.0
Black Matte
87193
95327871938.0
Gray Semi-Gloss
58193
95327581936.0
Red Semi-Gloss
51193
95327511933.0
Aluminum Semi-Gloss
88193
95327881937.0
Zinc Coat (unfinished)
89193
95327891936.0

About Us:
Mulberry offers an extensive wallplate selection in 40 materials and finishes–painted metal, stainless steel, brass, bronze, chrome, aluminum, and unbreakable thermoplastic. We make over 7,000 different wallplates, in hundreds of openings and combinations. Most are in stock.

Material:
Construction: Painted metal; cold-rolled steel, 0.030 inches thick

Mechanical:
Gang: 3
Size: Standard (4.5 in. high x 6.375 in. wide)
Size / Shape: Standard
Opening: (1) blank (1) duplex (1) blank
Mounting: (Blank) box mounting (3.281 in. between mounting holes) / (Duplex) device mounting / (Blank) box mounting (3.281 in. between mounting holes)

Standards:
Applicable Standards: UL 514D
Certification: UL Listed

Finishes: Available in a choice of (10) ten powder coat paint finishes; (1) one unfinished. Comes with 1/2 inch standard slotted 6-32 oval head screws in matching finishes.

Product Features:

  • Ideal for residential and commercial applications.
  • Made from the finest steel alloy and painted with a superior powder coat finish to assure durability.
  • Durable finish inhibits oxidation and helps prevent any chipping and scratching.
  • If needed, can later be painted in the field to match a new room décor.
  • Comes with matching screws.
  • Made in the U.S.A.

Box Quantity: 10


Download and Print PDF
